Customized copper alloy sliding bearings with lubrication grooves

Customized copper alloy sliding bearings may also be called solid bronze sliding bearings with lubrication grooves or specially shaped bronze turned sliding bearings.
The bushing is turned and milled from cast bronze. Features: The bearing performance of sliding bearings can be individually designed through the choice of alloy materials and the multiple possibilities of different lubrication groove shapes.
Custom copper alloy plain bearings are ideal for demanding applications in difficult conditions, which is why custom copper alloy plain bearings are the best solution for a variety of applications.
Customized copper alloy sliding bearings are provided exactly according to the user's specifications. Finish-turned copper alloy plain bearings are manufactured to order and special requirements including lubrication grooves and tolerances can also be considered and implemented.

Customized copper alloy sliding bearings

Product range at a glance
Standardized turned bronze plain bearings according to DIN ISO 4379
Suitable for oil and grease lubrication applications
Made from cast copper alloy (various alloys available)
Available in a variety of sizes with different designs: straight sleeves, flange sleeves and bearing bushes, etc.
A variety of special shapes can also be provided according to customer requirements
Product advantages
Unaffected by contaminants
Suitable for corrosive environments
Ideal for shock loads and vibrations
High load capacity
Very wear-resistant
Customized copper alloy sliding bearings
Application
Maritime and offshore engineering facilities
Construction machinery such as heavy commercial vehicles and excavators
General Mechanical Engineering
Lifting applications such as elevator systems
Pumping and conveying systems
Ropeways and rolling stock
Paper machinery
Etc.

Custom copper alloy sliding bearing with oil groove

Other typical characteristics:
Custom copper alloy plain bearings optionally available with grooves to hold lubricant in place
Requires external oil or grease lubrication
good corrosion resistance
Not sensitive to shock loads
Bushings are also ideal for storage in difficult environments, such as contaminated environments.

Custom copper alloy sliding gasket

Lubricating
Custom copper alloy sliding bearings are usually lubricated with grease, but oil can also be used. Due to lubrication, a lubricating film is formed between the sliding bearing and the shaft. This reduces friction and wear when using the bushing. All turned bronze plain bearings with an inner diameter of 14 mm or larger are equipped with axial lubrication grooves as standard. Additionally, additional lubricant can be retained in such lubrication grooves.
For heavily contaminated applications we recommend sealing the bearings to protect the bearings and lubricant.

Recommended oil groove type for customized copper alloy sliding bearings
