MXB-JGLX L-type Guide Rail High Corrosion Resistance

MXB-JGLX self-lubricating guide rails cover multiple properties such as high wear resistance, high temperature resistance, corrosion resistance, etc., and can provide reliable support for a variety of equipment including the automobile manufacturing industry. This product provides 17 standard products in the parameter table, and can also be customized by customers. Customers are required to provide drawings or samples.

Get A Quote

PREV：MXB-JSOL Self-Lubricating Guide Rail 2/3/4/5 Bolt Hole Type NEXT：MXB-JGLXS Copper Alloy CAC304 Guide Rail

Product Introduction
Parameter
Material Description
Contact Us

Product Features

1 Can work for a long time under oil-free conditions.

2 More suitable for low-speed and heavy-load workingconditions, with good wear resistance and extremely low frict.

3 Suitable for situations where oil film is difficult to form, such as reciprocating, rotating and intermittent movements.

4 Resistant to corrosion and oxidation.

5 Maintenance-free and long service life.

Why Choose Oilless Bearings

Reduce Manufacturing costs

There is no need for oil supply device, oil injection hole or oil groove processing, which can greatly save manufacturing costs.

Reduce Operating Costs

It greatly reduces the usage of lubricating oil, reduces equipment maintenance, and avoids hidden dangers caused by insufficient oil supply, effectively reducing operating costs.

Shorten Design Time

The oil-free design simplifies the product structure and effectively saves design time. We are professional ODM Suppliers of JGLX L-type Guide Rail High Corrosion Resistance

Conducive To Environmental Protection

No waste oil recycling is required, which is also beneficial to environmental protection.

Application Fields

High Temperature

·Steel factory

·Smelting furnace

·Drying equipment

·Baking oven

·Heat controller

Water Proof

·Dam gate

·Water pump

·Fluid switch structure

·Offshore structures

·Dock and silt machine equipment

Chemical Industry

·Chemical factory

·Electroplating equipment

·Wastewater treatment equipment

·Dyeing machinery

·Oil and chemical refining equipment

Energy

·Wind power

·New energy

Ship

·Deck crane

·Anchor

·Hatch cover

·Rudder arm

·Lifting machinery and lifting ring equipment

Automobile Manufacturing

·Stamping mold

·Welding structure

·Painting and drying line

·Metal conveyor belt

·Machine tools

Heavy Industry

·Steel pipe factory machinery

·Tire and paper mills

·Power plant

·Connecting toggle of mold injection machinery

Construction, Mining, Loading

·Mixers, grinders, pulverizers

·Construction machinery

·Mining equipment

·Connecting rod bearings

Bridges and Lift Rails

·Bridge bearings

·Beams, bridges, suspension bridges

·Nuclear energy related reactors

·Steam generator

unit:mm

Part No.	W	L	T	W1	H	Recommended Mounting Hole
						P	Size
JGLX-20×15	20	320	15	14.5	5	8	M8
JGLX-20×20			20
JGLX-20×25			25
JGLX-20×23			23		8
JGLX-20×28			28
JGLX-25×28	25	320 605	28	17.5	10	10
JGLX-25×33			33
JGLX-25×43			43
JGLX-30×38	30		38	19	15
JGLX-30×43			43
JGLX-30×53			53
JGLX-35×43	35		43	23		12	M10
JGLX-35×53			53
JGLX-35×63			63		20
JGLX-40×45	40		45	28		14	M12
JGLX-40×55			55
JGLX-40×65			65

Material Composition and Properities
Material	CuZn25Al5Mn3Fe3	CuSn5Pb5Zn5	CuAl10Ni5Fe5	CuSn12	CuZn25Al5Mn4Fe3
Density	8.0	8.9	7.8	8.9	8.0
Hardness HB	>210	>70	>150	>95	>250
Tensile Strength N/mm²	>750	>200	>600	>260	>800
Yield Strength N/mm²	>450	>90	>260	>150	>450
Elongation%	>12	>15	>10	>৪	>800
Coefficien of Linear Expansion 10^-5/℃	1.9	1.8	1.6	1.8	1.9
Limit Temp ℃	-40~+300	-40~+400	-40~+400	-40~+400	-40~+150
Max. Load N/mm²	100	60	50	70	120
Max. Speed (Dry) m/min	15	10	20	10	15
Max.PV N/mm²*m/min	200	60	60	80	200
Compression of Permanent Deformation 300N/mm²	<0.01	<0.05	<0.04	<0.05	<0.05
*Big demand with special materials is available.

Base Material Interchange
Material Codes	China Brands GB1176-87	Intenational ISO 1338	Germany DIN	Japan JIS	America ASTM(UNS)	England BS	Italy JM	Applicable conditions
JDB Casted Bronze	ZCuZn25AI5 Fe3Mn3	GCuZn25AI6 Fe3Mn3	DIN1709 G-CuZn25AI5	H5102 CAC304	B30-92 C86300	HTB2	JM18-1	High-load, low speed Commonly used
JDB-1Bronze	ZCuSn5 Pb5Zn5	GCuPb5 Sn5Zn5	DIN1705 G-CuSn5ZnPb	H5111 BC6	B30-92 C83600	LG2	JM7-15	Mid-load, low speed Commonly used
JDB-2Bronze	ZCuAI9Fe4 Ni4Mn2	GCuAI10 FeNiS	DIN17656 G-CuAI10Ni	H5114 AIBC3	B30-92 C95500	AB2	JM3-15	Mid-load, mid-speed, Commonly used
JDB-3Bronze	ZCuSn12		G-CuSn12	CAC503B	B30-92 C90800	PB2	JM1-15	Mid-load, low speed, Commonly used
JDB-5	ZCuZn25AI6 Fe3Mn3	GCuZn25AI6 Fe3Mn3	DIN1709 G-CuZn25AI5	H5102 CAC304	B30-92 C86300	HTB2	JM18-1	Over high load, low speed, High load used

Solid Lubricant
Lubricant	Features	Typical application
SL1 Graphite+add	Excellent resistance against chemical attacks and low friction, Temp limit 400℃	Suit for general machines and under atmosphere
SL4 PTFE+add	Lowest in friction and good of water Lubrication,Temp limit 300℃	Ship, hydraulic turbine, gas turbine, etc.

SUBMIT

About US

Zhejiang Mingxu Machinery Manufacturing Co., Ltd. Zhejiang Mingxu Machinery Manufacturing Co., Ltd., formerly known as Jiashan Mingxu Precision Machinery Factory, was founded in 2011. The company is located in the hinterland of the Yangtze River Delta Integrated Development Demonstration Zone, with location and convenient transportation. With more than ten years of manufacturing and R&D experience, the company has been deeply involved in the development and production of solid lubricating bearings, skateboards, slideways, and sliders. ODM Suppliers and Company of JGLX L-type Guide Rail High Corrosion Resistance in China. The product manufacturing adopts modern automation equipment, strictly implements the ISO2000 quality management system standard, and the main processes are processed by high-precision CNC machines. The company's main products cover a series of products such as JDB solid inlaid self-lubricating bearings, steel-copper sintered bearings, SF-1 self-lubricating bearings, SF-2 boundary self-lubricating bearings, and FB090 copper bearings. Widely used in automobile industry, construction machinery, metallurgical equipment, mining machinery, injection molding, mold, textile, printing and many other machinery manufacturing fields; Till now, the company's products have spread all over China and exported to many foreign countries, and are deeply recognized and loved by domestic and foreign customers.

Mingxu Machinery adheres to the service tenet of "quality-oriented high-quality service", and strive to provide customers with professional products and services. Supply Wholesale MXB-JGLX L-type Guide Rail High Corrosion Resistance. The company will continue to introduce talents, improve the management mechanism, integrity, development, innovation, and strive to build a world-class brand.

Certificate Of Honor

News

How does the proportion of metal additives in a graphite sliding bearing influence its tribological properties?
2024-12-20
Friction ReductionIncrease in Load-Bearing Capacity:The addition of me...
READ MORE
Do you know about linear bearings?
2024-12-18
‌Linear bearing is a linear motion system used in conjunction with a c...
READ MORE
How does the porosity of materials like bronze or sintered metals affect the lubrication properties of oilless bearings?
2024-12-16
The porosity of materials like bronze or sintered metals plays a cruci...
READ MORE
How does a DIN 9834 guide bushing with collar reduce tool vibration in precision turning or milling?
2024-12-13
A DIN 9834 guide bushing with collar plays a significant role in minim...
READ MORE

Product knowledge

What scenarios does the high corrosion resistance of JGLX guide rails make it more suitable for?

The high corrosion resistance of JGLX guide rails makes them particularly well-suited for scenarios involving harsh environments or corrosive substances.

One such scenario wherein the excessive corrosion resistance of JGLX guide rails is superb is in marine packages. Marine environments are known for their high tiers of humidity, saltwater publicity, and numerous corrosive dealers. When exposed to those factors through the years, conventional guide rails can also deteriorate and compromise the protection and overall performance of the equipment or equipment they may be supporting. However, JGLX manual rails' incredible resistance to corrosion ensures their longevity and reliability in such marine programs.

Similarly, JGLX Guide Rail High Corrosion Resistance are also highly suitable for installations in chemical manufacturing facilities or laboratories where corrosive chemicals or fumes are present. These environments pose big demanding situations, as exposure to corrosive materials can lead to fabric degradation and structural weakness. The high corrosion resistance of JGLX guide rails offers a dependable solution, offering extended durability and preserving their structural integrity even in the presence of corrosive agents.

Moreover, JGLX guide rails' resistance to corrosion makes them an extremely good choice for outside programs uncovered to harsh weather situations. For instance, in out of doors escalators or elevators, the guide rails are at once uncovered to rain, snow, severe sunlight, and temperature variations, which can cause corrosion if the rails aren't competently covered. By making use of JGLX guide rails with their excessive corrosion resistance, the chance of deterioration because of weather situations is mitigated, ensuring dependable operation and extended lifespan
